08B-1/K1/4 roller chain
JEDNOREDNI VALJKASTI LANAC DIN 8187 SA OBOSTRANIM HORIZONTALNIM NOSAČIMA K1 NA SVAKOM ČETVRTOM ČLANKU
| Code | 1004345 |
|---|---|
| Designation | 08B-1/K1/4 |
| Brand | SHWARTZ |
| Unit of measure | M |
| Catalogue Number | - |
| Pitch P (mm) | 12.7 |
| Pitch P (zoll) | 1/2 |
| Width between Inner plates b1 (mm) | 7.75 |
| Roller diameter d1 (mm) | 8.51 |
| Pin diameter d2 (mm) | 4.45 |
| Plate thickness t/T (mm) | 1.6 |
| Height h2 (mm) | 12 |
| G (mm) | 9.5 |
| F (mm) | 25.3 |
| W (mm) | 37 |
| T (mm) | 1.6 |
| h4 (mm) | 8.9 |
| d4 (mm) | 4.5 |
| Disposition of transport links | Every 4th link |
| Weight (kg) | 0.72 |
| OEM No. |
|---|
| Brand | Type | Model | Serial number |
|---|
YOUR PRICE with VAT: 0,00 RSD
The product is currently out of stock.
Send an inquiry and we will contact you soon.
Send an inquiry and we will contact you soon.
Quantity:
M
AGRIMAR d.o.o. makes maximum use of all its resources so that all items on this site are shown to you with correct names, specifications, photos, stock and prices. However, we cannot guarantee that all information and photos of items on this site are completely accurate.
